On November 16, the 2023 Data Center Science and Technology Achievement Award Ceremony was held at the 11th CDCC Annual Data Center Standards Summit. Haiwu's "atomized air-cooled heat pipe multi-connection technology" won the third prize of the Data Center Science and Technology Achievement Award!
The Data Center Science and Technology Achievement Award is known as the "Nobel Prize" in the IDC industry, and the award-winning technology is a breakthrough achieved by Haiwu with years of experience in temperature control design and implementation in the field of data centers.
01 Atomization cooling technology, power reduction by 15%
The high-pressure micro-mist method is used to improve the spraying efficiency, and the water consumption is controlled by real-time detection of the humidity of the outdoor air, which greatly reduces water consumption and further improves the operating energy efficiency.
02 Phase change heat transfer, system transmission power is reduced by 85%
The indoor refrigerant heat exchange efficiency on the evaporation side is high, reducing the refrigerant flow and reducing the power of the pump, and the condensing side pump only provides the spray cycle of the unit, and the spray water pump power of the air-cooled condenser (@300kW) is 0.75kW, and the power of the fluorine pump is 1.5kW.
03 High-efficiency cooling core devices, COP increased by 40%+
Adopting magnetic levitation compressor technology, the system runs without oil, eliminating oil system maintenance and friction loss, the impeller adopts direct drive type, eliminating the mechanical loss caused by the gearbox, and using permanent magnet synchronous motor, motor efficiency up to 98%, variable frequency drive, stepless speed regulation, starting current as low as 2A.
High reliability
Excellent performance
Economic benefits
Energy conservation and carbon reduction
